Summary

In modern electrical engineering, the choice is between tool-free connector systems such as the three-point bayonet locking and tool-free screw connectors (WSS). A major problem with many installation requirements is the need for tools for assembly as well as the precise setting of torques, which can be critical in the acceptance process. The three-point bayonet locking solves these problems through complete contacting without a torque lock, which can eliminate errors in the production step and is achieved through a single tool and action. This solution is compatible with all devices from the field to the processing flange and ensures the processing quality of the entire flange connector set. The technology uses 100% compatibility with standard M12x1 shields and protects the circuit with protection classes IP65 and IP67 as well as the IP69K standard. These specifications also meet the strict IEC 61373:2010-10 requirements and the statutory RoHS criteria.

Title

M12 circular connector with bayonet quick lock

Description

M12 bayonet quick lock. Tool-free, safe, fast and tactile three-point bayonet locking

Keywords

sind, oder, hand, dass, standard, sales, adobe, stock, home
